24 Gigabit Ports with 10G Uplinks: Features 24 x 10/100/1000 Mbps RJ45 ports and 4 x SFP+ 10 Gigabit uplink ports for high-speed network connectivity and backbone access .
Cloud & App Management: Simplifies network deployment and maintenance with the Ruijie Cloud platform and Reyee mobile app, enabling zero-touch provisioning and remote monitoring .
Layer 2+ Features: Supports advanced Layer 2 functions including VLANs (up to 4094), Link Aggregation, IGMP Snooping, and Port Mirroring, along with a management interface (SVI) .
Robust Security & Reliability: Provides comprehensive security with ACLs, 802.1x authentication, DHCP Snooping, and port isolation. It also features 6KV surge protection on all ports to prevent damage from electrical spikes .
High Performance: Delivers a switching capacity of 336 Gbps and a forwarding rate of up to 108 Mpps , ensuring smooth data flow for demanding applications.
Enhanced Network Efficiency: Includes support for EEE (Energy Efficient Ethernet), STP/RSTP for loop prevention, and LLDP for network discovery, helping to maintain a stable and efficient network .
DatasheetThe Ruijie Reyee RG-NBS3200-24GT4XS is a high-performance, cloud-managed Layer 2+ Gigabit switch designed for businesses requiring reliable and scalable network access . Featuring 24 Gigabit RJ45 ports for high-speed device connectivity and 4 SFP+ 10G uplink ports, it delivers a switching capacity of 336 Gbps to handle bandwidth-intensive tasks with ease . Ideal for enterprise, hospitality, education, and retail environments, this switch simplifies network management through the Ruijie Cloud platform and mobile app, allowing for intuitive configuration, monitoring, and maintenance from anywhere . Its robust build, including 6KV port surge protection, ensures stable and secure operations in demanding conditions .
